WALL ELBOW TIGRIS 16x1/2 DOUBLE K5 PPSU
Product code
1750267
No product description available.
Product details
Technical specifications
Housing materialPlastic
Material qualityOther
Surface protectionUntreated
ShapeRight-angled
System-specifictrue
Nominal diameter connection 1Other
Outer pipe diameter connection 116 mm
Nominal diameter connection 21/2 inch (15)
ConnectionInternal thread conical (NPT)
Thread size tap connection1/2 inch
Length of connection 152 mm
Working length connection 127 mm
Wall thickness, connection 17.4 mm
Length of connection 229 mm
Working length connection 212 mm
Product codes
SAPCMO299
HPAC1750267
PLC1750267
GTIN/EAN4026294919305
Manufacturer part number3079857
Vendor material number3079857
Basic information
Package measurements (L x W x H)76 x 75 x 51 mm
Package volume0.291 l
Package weight0.088 kg
Base uniteach
Package units10 / 20 / 1440
Package contents–
UNSPSC40141720
BrandWAVIN
VendorWAVIN FINLAND OY
Documents (9)
Brochures & documents
Links
Sustainability information
Features
Warranty (years)1
Type ApprovalYes
Documents (1)
Sustainability brochures & documents
