TAPPING CONNECTOR 1x6(10)/6x1.5(2,5)mm2 YEL/GREY
Product code
1939380
No product description available.
Product details
Technical specifications
Connectable conductor cross section fine-strand without cable end sleeve0.5 ... 10 mm²
Connectable conductor cross section fine-strand with cable end sleeve1.5 ... 6 mm²
Connectable conductor cross section solid-core1 ... 10 mm²
Connectable conductor cross section multi-wired0.5 ... 6 mm²
Rated current In41 A
Rated voltage800 V
Type of electrical connection 1Spring clamp connection
Type of electrical connection 2Spring clamp connection
Number of levels1
Number of clamp positions per level7
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature105 ... 105 °C
Inflammability class of insulation material according to with UL94V0
Width9 mm
Product codes
SAPCZA626
PLC1939380
STK1939380
GTIN/EAN4066966215847
Manufacturer part number2006-8031/000-053
Vendor material number2006-8031/000-053
Basic information
Package measurements (L x W x H)75 x 40 x 9 mm
Package volume0.027 l
Package weight0.016 kg
Base uniteach
Package units1 / 12 / 576
Package contents–
UNSPSC39121421
BrandWAGO
VendorWAGO FINLAND OY
