FREQUENCY CONVERTER VACON 100X 30kW/61A, IP66
Product code
3888656
No product description available.
Product details
Technical specifications
Mains voltage380 ... 500 V
Mains frequency50/60 Hz
Number of phases input3
Number of phases output3
Max. output frequency320 Hz
Max. output voltage500 V
Nominal output current I2N61 A
Max. output at linear load at rated output voltage30 kW
Number of analogue outputs1
Number of analogue inputs2
Number of digital outputs1
Number of digital inputs6
With control elementfalse
Application in industrial area permittedtrue
Application in domestic- and commercial area permittedtrue
Product codes
SAPDAZ715
PLC3888656
STK3888656
GTIN/EAN5714853303380
Manufacturer part number132H1647
Vendor material number132H1647
Basic information
Package measurements (L x W x H)730 x 400 x 360 mm
Package volume105.12 l
Package weight33.8 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121007
BrandVACON
VendorDANFOSS OY AB
