MOTOR CIRCUIT-BREAKER CL10, 2.2...3.2A, 42A

Name: MOTOR CIRCUIT-BREAKER CL10, 2.2...3.2A, 42A
Brand: SIEMENS
SKU: COX289

Product code

3720845

No product description available.

Product details

Overload release current setting2,2...3,2 A

Adjustment range undelayed short-circuit release42...42 A

Phase failure sensitivetrue

Switch off techniqueMagnetic

Rated operating voltage690...690 V

Rated permanent current Iu3,2 A

Rated operation power at AC-3, 230 V0,55 kW

Rated operation power at AC-3, 400 V1,1 kW

Type of electrical connection of main circuitScrew connection

Type of control elementOther

Device constructionBuilt-in device fixed built-in technique

With integrated auxiliary switchfalse

With integrated under voltage releasefalse

Number of poles3

Rated short-circuit breaking capacity lcu at 400 V, AC100 kA

SAPCOX289

PLC3720845

STK3720845

GTIN/EAN662643921939

Manufacturer part number3RV2011-1DA10

Vendor material number3RV2011-1DA10

Package measurements (L x W x H)102 x 102 x 49 mm

Package volume0.51 l

Package weight0.345 kg

Base uniteach

Package units1

Package contents1

UNSPSC39121601

BrandSIEMENS

VendorSIEMENS OY
