CONTACTOR 3RT1055-6NP36
Product code
3821417
No product description available.
Product details
Technical specifications
Rated control supply voltage AC 50 Hz200 ... 277 V
Rated control supply voltage AC 60 Hz200 ... 277 V
Rated control supply voltage DC200 ... 277 V
Voltage type for actuatingAC/DC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitScrew connection
Rated operation current Ie at AC-1, 400 V185 A
Rated operation current Ie at AC-3, 400 V150 A
Rated operation power at AC-3, 400 V84 kW
Rated operation current Ie at AC-4, 400 V132 A
Rated operation power at AC-4, 400 V75 kW
Number of auxiliary contacts as normally open contact2
Number of auxiliary contacts as normally closed contact2
Modular versiontrue
Product codes
SAPGCB148
PLC3821417
STK3821417
GTIN/EAN4011209507425
Manufacturer part number3RT1055-6NP36
Vendor material number3RT1055-6NP36
Basic information
Package measurements (L x W x H)270 x 230 x 195 mm
Package volume12.11 l
Package weight3.5 kg
Base uniteach
Package units1
Package contents1
UNSPSC39121529
BrandSIEMENS
VendorSIEMENS OY
