CONTACTOR LC1SKGC310P7 20A AC1 230VAC

TeSys SK mini contactor, 3p (3 NO), AC-3, 690 V 9A, 230 V AC coil. range: TeSys - product name: TeSys SK - product or component type: mini contactor - device short name: LC1SKGC - contactor application: motor control, resistive load - utilisation category: AC-1, AC-3 - poles description: 3P - pole contact composition: 3 NO - [Ue] rated operational voltage: 690 V AC <= 400 Hz for signalling circuit, 690 V AC 50/60 Hz for power circuit - [Ie] rated operational current: 20 A (<= 50 °C) AC AC-1, 9 A at <= 400 V AC AC-3 - motor power kW: 1.1 kW at 220...230 V AC 50/60 Hz, 4 kW at 380...415 V AC 50/60 Hz, 4 kW at 660...690 V AC 50/60 Hz - auxiliary contact composition: 1 NO - [Ith] conventional free air thermal current: 10 A at <= 55 °C for signalling circuit, 20 A at <= 55 °C for power circuit - Irms rated making capacity: 85 A AC conforming to IEC 60947, 85 A AC conforming to NF C 63-110 - rated breaking capacity: 68 A at <= 400 V conforming to IEC 60947, 68 A at <= 400 V conforming to NF C 63-110 - associated fuse rating: 10 A gI for signalling circuit conforming to IEC 60947, 10 A gI for signalling circuit conforming to VDE 0660, 20 A gI at <= 440 V for power circuit - [Ui] rated insulation voltage: 690 V for power circuit conforming to BS 5424, 690 V for power circuit conforming to CSA C22.2 No 14, 690 V for power circuit conforming to IEC 60947, 690 V for power circuit conforming to UL 508, 690 V for power circuit conforming to VDE 0110 group C - mounting support: panel, rail - standards: BS 5424, IEC 60947, NF C 63-110, VDE 0660 - product certifications: CSA, UL - connections - terminals: connector 1 cable(s) 0.35...6 mm² - cable stiffness: flexible - with cable end, connector 1 cable(s) 0.5...6 mm² - cable stiffness: flexible - without cable end, connector 1 cable(s) 1.5...6 mm² - cable stiffness: solid, connector 2 cable(s) 0.35...1.5 mm² - cable stiffness: flexible - with cable end, connector 2 cable(s) 0.35...2.5 mm² - cable stiffness: flexible - without cable end, connector 2 cable(s) 1.5...4 mm² - cable stiffness: solid - operating time: 6...8 ms coil de-energisation and NO opening, 7...14 ms coil energisation and NO closing - mechanical durability: 10 Mcycles. Benefits: .. Applications: ..
