SINGLE-STAGE PUMP GRUNDFOS TP 80-520/2-A-F-A-BQQE 400D

Product code
96108724
No product description available.

Product details

Technical specifications

Material pump casingCast iron
Material quality pump casingCast iron GG 25 (GJL-250)
Material impeller/pump wheelCast iron
Material quality impeller/pump wheelCast iron EN-GJS-400-15 (GGG 40)
Volume flow rate (BEP)113 m³/h
Discharge head at flow rate (BEP)415.7 kPa
Max. discharge flow113 m³/h
Max. static height52 m
Max. operating pressure16 bar
Double pumpfalse
Electrical connectionTerminals
Rated voltage380 ... 415 V
Number of phases3
Frequency50 Hz
Nominal current33.36 A

Product codes

SAPCGX172
HPACCGX172
PLC96108724
GTIN/EAN5700396976907
Manufacturer part number96108724
Vendor material number96108724

Basic information

Package measurements (L x W x H)1200 x 800 x 1190 mm
Package volume1142.4 l
Package weight212 kg
Base uniteach
Package units1
Package contents
UNSPSC40151503
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB

Documents (1)
