SINGLE-STAGE PUMP GRUNDFOS TP 40-360/2-A-F-A-BQQE 400D
Product code
4616040
No product description available.
Product details
Technical specifications
Material pump casingCast iron
Material quality pump casingCast iron GG 25 (GJL-250)
Material impeller/pump wheelCast iron
Material quality impeller/pump wheelCast iron EN-GJS-400-15 (GGG 40)
Volume flow rate (BEP)26.6 m³/h
Discharge head at flow rate (BEP)287.26 kPa
Max. discharge flow26.6 m³/h
Max. static height36 m
Max. operating pressure16 bar
Double pumpfalse
Electrical connectionTerminals
Rated voltage380 ... 415 V
Number of phases3
Frequency50 Hz
Nominal current7.9 A
Product codes
SAPCGX140
HPAC4616040
PLC4616040
GTIN/EAN5700395308815
Manufacturer part number96086925
Vendor material number96086925
Basic information
Package measurements (L x W x H)800 x 400 x 557 mm
Package volume178.24 l
Package weight89 kg
Base uniteach
Package units1
Package contents–
UNSPSC40151503
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB
