SINGLE-STAGE PUMP GRUNDFOS TP 32-230/2-A-F-A-BQQE 400Y
Product code
98278909
No product description available.
Product details
Technical specifications
Material pump casingCast iron
Material quality pump casingCast iron GG 25 (GJL-250)
Material impeller/pump wheelStainless steel
Material quality impeller/pump wheelStainless steel 304 (1.4301)
Volume flow rate (BEP)7.1 m³/h
Discharge head at flow rate (BEP)166.67 kPa
Max. discharge flow7.1 m³/h
Max. static height23 m
Max. operating pressure10 bar
Double pumpfalse
Electrical connectionTerminals
Rated voltage380 ... 415 V
Number of phases3
FrequencyOther
Nominal current1.9 A
Product codes
SAPCGX234
HPACCGX234
PLC98278909
GTIN/EAN5711492350942
Manufacturer part number98278909
Vendor material number98278909
Basic information
Package measurements (L x W x H)400 x 300 x 654 mm
Package volume78.48 l
Package weight29 kg
Base uniteach
Package units1
Package contents–
UNSPSC40151503
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB
Documents (1)
Images
