SINGLE-STAGE PUMP GRUNDFOS TP 100-160/2-A-F-A-BQQE 400D
Product code
96109189
No product description available.
Product details
Technical specifications
Material pump casingCast iron
Material quality pump casingCast iron GG 25 (GJL-250)
Material impeller/pump wheelCast iron
Material quality impeller/pump wheelCast iron EN-GJS-400-15 (GGG 40)
Volume flow rate (BEP)76.2 m³/h
Discharge head at flow rate (BEP)125.49 kPa
Max. discharge flow76.2 m³/h
Max. static height16 m
Max. operating pressure16 bar
Double pumpfalse
Electrical connectionTerminals
Rated voltage380 ... 415 V
Number of phases3
Frequency50 Hz
Nominal current7.9 A
Product codes
SAPCGX202
HPACCGX202
PLC96109189
GTIN/EAN5700396981666
Manufacturer part number96109189
Vendor material number96109189
Basic information
Package measurements (L x W x H)800 x 600 x 797 mm
Package volume382.56 l
Package weight111 kg
Base uniteach
Package units1
Package contents–
UNSPSC40151503
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB
