CIRCULATOR PUMP GRUNDFOS MAGNA 32-100 1X230V 180XR25
Product code
4615513
No product description available.
Product details
Technical specifications
Material pump casingCast iron
Material quality pump casingCast iron GG 20 (GJL-200)
Material impeller/pump wheelOther
Material quality impeller/pump wheelOther
Volume flow rate (BEP)5.65 m³/h
Discharge head at flow rate (BEP)66.44 kPa
Max. discharge flow5.65 m³/h
Max. static height10 m
Max. operating pressure10 bar
Double pumpfalse
Electrical connectionOther
Rated voltage230 ... 230 V
Number of phases1
Frequency50/60 Hz
Nominal current1.47 A
Product codes
SAPADO511
HPAC4615513
PLC4615513
GTIN/EAN5710626493326
Manufacturer part number97924257
Vendor material number97924257
Basic information
Package measurements (L x W x H)233 x 225 x 272 mm
Package volume14.26 l
Package weight5.25 kg
Base uniteach
Package units1 / 15
Package contents–
UNSPSC40101806
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB
The country of origin stated by the supplierFinland
Documents (8)
Images
Brochures & documents
Links
Sustainability information
Features
Energy efficiency index (EEI)0.18
Availability of spare parts after discontinuation (years)2
