MCB GW92004 4X1A C-CURVE 6KA
Product code
3202303
The product cannot be delivered from web store
The product is available in express stores
Muurala Mega Express
Olarinluoma Express
No product description available.
Product details
Technical specifications
Built-in depth72 mm
Release characteristicC
Number of poles (total)1
Number of protected poles1
Rated current4 A
Rated voltage400 V
Rated insulation voltage Ui500 V
Rated impulse withstand voltage Uimp4 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6 kA
Voltage typeAC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V10 kA
Frequency50 ... 60 Hz
Current limiting class3
Concurrently switching neutral conductorfalse
Over voltage category3
Product codes
SAPDBR451
PLC3202303
STK3202303
GTIN/EAN8011564057012
Manufacturer part numberGW92004
Vendor material numberGW92004
Basic information
Package measurements (L x W x H)96 x 78 x 18 mm
Package volume0.135 l
Package weight0.135 kg
Base uniteach
Package units1 / 6 / 24 / 2304
Package contentsâ
UNSPSC39121603
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
