LED STRIP BASE 24V 14,4W/M IP20 24V 4000K 120LED
Product code
4123279
No product description available.
Product details
Technical specifications
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Number of nodes per meter120
Lamp power per meter14.4 W
Luminous flux per meter1410 lm
Voltage typeDC
Lamp voltage24 ... 24 V
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Energy efficiency class of the light source according to EU regulation 2019/2015E
Rated life time L70/B50 at 25 °C50000 h
Degree of protection (IP)IP20
Protection classIII
Max. system power72 W
Product codes
SAPCSA224
PLC4123279
STK4123279
GTIN/EAN6430080490974
Manufacturer part numberJPL-VN14,4W120-24V-4000K
Vendor material number4123279
Basic information
Package measurements (L x W x H)240 x 212 x 12 mm
Package volume0.611 l
Package weight0.13 kg
Base uniteach
Package units1 / 20 / 240 / 960
Package contents–
UNSPSC39111544
BrandARTEN
VendorARTEN OY
