ABB SMART BUILDINGS

CIRCUIT BREAKER S300P 4-POLE 3+N B-CHAR. 8A

Name: CIRCUIT BREAKER S300P 4-POLE 3+N B-CHAR. 8A
Brand: ABB SMART BUILDINGS
SKU: DCU218

Product code

3216004

No product description available.

Product details

Built-in depth69 mm

Release characteristicB

Number of poles (total)4

Number of protected poles3

Rated current8 A

Rated voltage415 V

Rated insulation voltage Ui500 V

Rated impulse withstand voltage Uimp6 kV

Voltage typeAC/DC

Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V25 kA

Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V50 kA

Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V25 kA

Frequency50 ... 60 Hz

Power loss6.4 W

Flush-mounted installationfalse

SAPDCU218

PLC3216004

STK3216004

GTIN/EAN4016779086097

Manufacturer part number2CDS383103R0085

Vendor material number3216004

Package measurements (L x W x H)88 x 70 x 69 mm

Package volume0.425 l

Package weight0.496 kg

Base uniteach

Package units1 / 24

Package contents–

UNSPSC39121603

BrandABB SMART BUILDINGS

VendorABB OY PJKOJEET, UPS JA SOLAR
