CONTACTOR AF52-30-00-14

Product code
3707017
KONTAKTOR AF52-30-00-14 250-500V
AF52 contactors are used for controlling power circuits up to 690 V AC and 220 V DC. They are mainly used for controlling 3-phase motors, non-inductive or slightly inductive loads. AF... contactors include an electronic coil interface accepting a wide control voltage Uc min. ... Uc max. Only four coils cover control voltages between 24...500 V 50/60 Hz or 20...500 V DC. AF contactors can manage large control voltage variations. One coil can be used for different control voltages used worldwide without any coil change. AF contactors have built-in surge protection and do not require additional surge suppressors. The AF... series 1-stack 3-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 3 main poles, front and side-mounted add-on auxiliary contact blocks (mechanically-linked auxiliary contacts compliant with Annex L of IEC 60947-5-1. N.C. mirror contacts compliant with Annex F of IEC 60947-4-1) - Control circuit: AC or DC operated - Accessories: a wide range of accessories is available.

Product details

Technical specifications

Rated control supply voltage AC 50 Hz250 ... 500 V
Rated control supply voltage AC 60 Hz250 ... 500 V
Rated control supply voltage DC250 ... 500 V
Voltage type for actuatingAC/DC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitScrew connection
Operating voltage AC 50 Hz690 ... 690 V
Operating voltage AC 60 Hz690 ... 690 V
Rated operation current Ie at AC-1, 400 V100 A
Rated operation current Ie at AC-3, 400 V53 A
Rated operation power at AC-3, 400 V22 kW
Rated operation power NEMA29.828 kW
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0

Product codes

SAPANY782
PLC3707017
STK3707017
GTIN/EAN3471523132344
Manufacturer part numberAF52-30-00-14
Vendor material number3707017

Basic information

Package measurements (L x W x H)126 x 55 x 111 mm
Package volume0.769 l
Package weight1.05 kg
Base uniteach
Package units1
Package contents
UNSPSC39121529
BrandABB
VendorABB OY PJKOJEET, UPS JA SOLAR
