CONTACTOR AF370-30-11-13
Product code
3706498
KONTAKTOR#AF370-30-11-13#100-250V
A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 1000 V. Operated with wide control voltage range 100-250 V, 50/60 Hz and DC
Product details
Technical specifications
Rated control supply voltage AC 50 Hz100 ... 250 V
Rated control supply voltage AC 60 Hz100 ... 250 V
Rated control supply voltage DC100 ... 250 V
Voltage type for actuatingAC/DC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitRail connection
Operating voltage AC 50 Hz1000 ... 1000 V
Operating voltage AC 60 Hz1000 ... 1000 V
Rated operation current Ie at AC-1, 400 V600 A
Rated operation current Ie at AC-3, 400 V370 A
Rated operation power at AC-3, 400 V200 ... 200 kW
Rated operation power NEMA223.71 kW
Number of auxiliary contacts as normally open contact1
Number of auxiliary contacts as normally closed contact1
Product codes
SAPANY703
PLC3706498
STK3706498
GTIN/EAN7320500481899
Manufacturer part numberAF370-30-11-13
Vendor material number3706498
Basic information
Package measurements (L x W x H)225 x 140 x 180 mm
Package volume5.67 l
Package weight5.31 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121529
BrandABB
VendorABB OY PJKOJEET, UPS JA SOLAR
