CONTACTOR AF205-30-00-11
Product code
3706399
No product description available.
Product details
Technical specifications
Rated control supply voltage AC 50 Hz24 ... 60 V
Rated control supply voltage AC 60 Hz24 ... 60 V
Rated control supply voltage DC20 ... 60 V
Voltage type for actuatingAC/DC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitRail connection
Operating voltage AC 50 Hz1000 ... 1000 V
Operating voltage AC 60 Hz1000 ... 1000 V
Rated operation current Ie at AC-1, 400 V350 A
Rated operation current Ie at AC-3, 400 V205 A
Rated operation power at AC-3, 400 V110 kW
Rated operation power NEMA111.855 kW
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Product codes
SAPANY660
PLC3706399
STK3706399
GTIN/EAN7320500480502
Manufacturer part numberAF205-30-00-11
Vendor material number3706399
Basic information
Package measurements (L x W x H)150 x 105 x 152 mm
Package volume2.394 l
Package weight3.19 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121529
BrandABB
VendorABB OY PJKOJEET, UPS JA SOLAR
