CONTACTOR AF190-30-11-13
Product code
3706394
KONTAKTOR#AF190-30-11-13#100-250V
A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 1000 V. Operated with wide control voltage range 100-250 V, 50/60 Hz and DC
Product details
Technical specifications
Rated control supply voltage AC 50 Hz100 ... 250 V
Rated control supply voltage AC 60 Hz100 ... 250 V
Rated control supply voltage DC100 ... 250 V
Voltage type for actuatingAC/DC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitRail connection
Operating voltage AC 50 Hz1000 ... 1000 V
Operating voltage AC 60 Hz1000 ... 1000 V
Rated operation current Ie at AC-1, 400 V275 A
Rated operation current Ie at AC-3, 400 V190 A
Rated operation power at AC-3, 400 V90 ... 90 kW
Rated operation power NEMA93.213 kW
Number of auxiliary contacts as normally open contact1
Number of auxiliary contacts as normally closed contact1
Product codes
SAPANY655
PLC3706394
STK3706394
GTIN/EAN7320500480434
Manufacturer part numberAF190-30-11-13
Vendor material number3706394
Basic information
Package measurements (L x W x H)150 x 105 x 152 mm
Package volume2.394 l
Package weight3.228 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121529
BrandABB
VendorABB OY PJKOJEET, UPS JA SOLAR
