CONTACTOR AF116-30-11-11
Product code
3706158
KONTAKTOR#AF116-30-11-11#24-60V
A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 690 V. Operated with wide control voltage range 24-60 V, 50 and 60 Hz, 20-60 V DC
Product details
Technical specifications
Rated control supply voltage AC 50 Hz24 ... 60 V
Rated control supply voltage AC 60 Hz24 ... 60 V
Rated control supply voltage DC20 ... 60 V
Voltage type for actuatingAC/DC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitCable clamp
Operating voltage AC 50 Hz690 ... 690 V
Operating voltage AC 60 Hz690 ... 690 V
Rated operation current Ie at AC-1, 400 V160 A
Rated operation current Ie at AC-3, 400 V116 A
Rated operation power at AC-3, 400 V55 kW
Rated operation power NEMA55.928 kW
Number of auxiliary contacts as normally open contact1
Number of auxiliary contacts as normally closed contact1
Product codes
SAPANY577
PLC3706158
STK3706158
GTIN/EAN7320500476352
Manufacturer part numberAF116-30-11-11
Vendor material number3706158
Basic information
Package measurements (L x W x H)150 x 90 x 126 mm
Package volume1.701 l
Package weight1.774 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121529
BrandABB
VendorABB OY PJKOJEET, UPS JA SOLAR
